HTp Series Small Axial Piston Pump for Road Grader
Condition:New without factory packaging
Model:0 510 525 311
Pressure:280 BAR
RPM:3500 RPM
Shipping Weight:10.6 lbs
Shipping Dimensions:8.5 x 7.75 x 6.5 in
SKU:D963875 (VIT08)
Category:Hydraulic Gear Pumps
Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. is one of the leading manufacturers and suppliers of htp series small axial piston pump for road grader in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Also, OEM&ODM service is available.
| Series | Nominal Displacement (ml/r) | E Intermediate Shell (mm) | D Rear Housing (mm) | Pressure (MPa) | Speed (r/min) | Input Power (KW) | Volumetric Efficiency (≥%) | Total Efficiency (≥%) | Weight (kg) | ||
| Rated | Max | Rated | Max | ||||||||
| HTP1 | 10 | 105 | 83 | 23 | 31.5 | 2500 | 2800 | 9.26 | 91 | 83 | 12.1 |
| 16 | 112 | 90 | 14.81 | 12.5 | |||||||
| 20 | 117 | 95 | 18.52 | 12.8 | |||||||
| 25 | 119 | 99 | 23.15 | 13.1 | |||||||
| 32 | 122 | 102 | 23 | 28 | 29.63 | 92 | 83 | 13.7 | |||
| 40 | 125 | 104 | 37.04 | 14.2 | |||||||
| 45 | 130 | 108 | 16 | 20 | 33.33 | 14.6 | |||||
| 50 | 136 | 114 | 37.04 | 14.8 | |||||||
| HTP2 | 32 | 78 | 113 | 23 | 31.5 | 2200 | 2800 | 26.07 | 92 | 83 | 20.2 |
| 40 | 81 | 118 | 32.59 | 20.6 | |||||||
| 50 | 84 | 122 | 40.74 | 21.2 | |||||||
| 63 | 89 | 126 | 23 | 28 | 51.33 | 22 | |||||
| 80 | 95 | 138 | 65.19 | 23 | |||||||
| 100 | 111 | 173 | 20 | 25 | 65.19 | 24.1 | |||||
| HTP3 | 63 | 138 | 99 | 23 | 28 | 2250 | 2800 | 52.5 | 92 | 83 | 29.5 |
| 100 | 155 | 116 | 83.33 | 31.2 | |||||||
| 125 | 160 | 121 | 104.17 | 32.5 | |||||||
| 140 | 166 | 127 | 116.67 | 33.6 | |||||||
| 160 | 172 | 133 | 133.33 | 34.4 | |||||||
| 180 | 179 | 140 | 20 | 25 | 120 | 35.4 | |||||
| 200 | 188 | 149 | 116.67 | 36.3 | |||||||
| 220 | 197 | 158 | 114.58 | 37.3 | |||||||
Notes: The upper table lists specification of single pump,the specification of double pump of multiple pump is the same as that of single pump except input power is sum of that of single pump
Notes:
1.Max. permissible degree of contamination of the oil is according to GB/T14039-19/16.
2.For the volumetric efficiency under non-nominal working condition(pressure and speed),
refer to the working performance curves.
3.If do not need oil transfer between each of pumps in series,contact to our company .
4. In addition to the size of the installation of connections,the other dimensions in order to prevail
in kind.
