Hydraulic Pump
Your Professional Hydraulic Pump Supplier!
Established in 2012, Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. stands as one of China's pioneering enterprises specializing in the research, development, manufacturing, and distribution of hydraulic pumps. Under the brand "Xinlaifu," the company has dedicated itself to advancing hydraulic technology, focusing on hydraulic pumps, motors, and components, while striving to deliver superior hydraulic solutions to a global clientele.
Global Reach
Over the past 12 years, Xinlaifu has served over 10,000 enterprises across 100+ cities in China and exported its renowned XLF series plunger pumps (including A2F, A4V, A6V, A7V, A8V, A10V, and A11V models) to markets in Canada, the U.S., Mexico, Brazil, Norway, Italy, France, the UK, Russia, South Africa, Kenya, Saudi Arabia, and beyond.
Professional Team
We have over 300 employees and a dedicated hydraulic pump R&D center, bringing together a team of experienced technical experts committed to continuous innovation to meet ever-changing market demands.
Wide Applications
Xinlaifu's hydraulic pumps are trusted in critical industries such as steel production, power generation, construction and mining machinery, industrial equipment, metallurgy, injection molding, oil drilling.
Quality Assurance
With ISO 9001 quality management system certification, we ensure that every product meets strict international standards, guaranteeing consistent and reliable product quality.
Specification
|
Max Pressure |
5000 PSI / 350 bar / 35 MPa |
|
Materials |
Anodized Aluminum, Brass, Polysulfone, Stainless Steel |
|
Seal Materials |
Buna-N,Teflon |
|
Outlet Port |
Male Quick-test |
|
Pressure Media |
Liquid |
|
Min Operating Temperature |
-29 °F / -34 °C |
|
Max Operating Temperature |
140 °F / 60 °C |
|
Fine Adjustment Resolution |
0.01 Psi / 70 Pa |
|
Reservoir Volume |
4.2 Fl. oz |
|
Length |
5.7 in / 15 cm |
|
Width |
6 in / 16 cm |
|
Height |
10.6 in / 27 cm |
Benefits Of Hydraulic Pump
Increased Efficiency:
Hydraulic pumps are more efficient than other types of pumps, such as electric or pneumatic pumps. These pumps use less energy to operate and generate higher pressures with less power.
01
Increased Precision:
Given the design of the hydraulic pumps, they can deliver precise results. Hence you get better control over the flow parameters of the system.
02
Increased Safety:
Hydraulic pumps are much safer to use than other pumps. This is because they are less likely to cause injuries due to their lack of moving parts.
03
Reduced Maintenance:
Hydraulic pumps require less maintenance than other types of pumps. Their design has fewer moving parts, which means there are fewer parts that can break or wear out.
04
Increased Durability:
Hydraulic pumps are more durable than other pumps. This is because they are made from high-quality materials that can withstand constant use.
05
Our Best-Selling Hydraulic Pump Types
Axial Piston Pump
An axial piston pump has a number of pistons (usually an odd number) arranged in a circular array within a housing which is commonly referred to as a cylinder block, rotor or barrel.
Axial Piston Motor
Axial piston motors are based on the basic principle of an axial piston pump. The main feature of this motor type is the axis-parallel arrangement of the pistons in a cylinder drum around the axis of rotation.
Components of Hydraulic Pump
1. Casing
The casing is the hydraulic pump's external part designed to ensure safety for the internal parts. Some pumps use aluminum casings, while others use cast iron castings. The casing's main purpose is to prevent fluid from splashing outside the pump. The component also prevents the hydraulic system from getting damaged if a heavy weight falls on the system.
2. Runner Vanes
There is a rotary part of the hydraulic pump known as a runner that rotates inside the pump casing. A number of vanes rotate along with the rotation of the runner. The fluid inside the pump also rotates with the rotation of the runner vanes. The result is an increase in fluid pressure. These vanes are also essential for cooling the system and lubricating it.
3. Shaft
A shaft is used to assemble the runner. A steel or stainless steel shaft is used for the assembly. The shaft size can be adjusted based on the runner.
4. Bearings
For the runner to rotate, bearings are needed. The hydraulic system and pump rely heavily on this component.
5. Sealing
Fluid leaks from the pump can be prevented by the seal. Pumps usually fail because bearing components are damaged. Bearing components can be protected from contaminants and coolants by means of a seal.
6. Oil Storage Tank
It contains non-compressible fluids (including hydraulic oil). The tank also protects the hydraulic oil from contamination. In this way, the storage tank keeps the hydraulic system in good working order.
7. Pipeline
A pipeline inside a system is easy to install, but the most important thing is that it transports hydraulic fluid between different parts of the system.
8. Electric Motor
Motors are used to drive the driving shaft inside the system. From there, the driver gear is driven. An electric motor is thus used to power the pump.
9. Hydraulic Actuator
A hydraulic actuator is a component that transforms hydraulic energy into mechanical power in order to accomplish the desired effect.
A hydraulic actuator looks like this:
● Linear movement is generated by the hydraulic cylinder.
● A hydraulic motor produces torque and rotates the cylinder.
10. Relief Valve
The relief valve controls the pressure within the hydraulic system. Different types of relief valves are available. By means of a pressure relief valve, excess fluid pressure is returned to the inlet.
Applications Of Hydraulic Pump
Automotive Industry:
Hydraulic pumps are used extensively in automotive applications, such as power steering, brakes, and transmission systems.
Construction Equipment:
Hydraulic pumps are also used in construction equipment, such as excavators and bulldozers.
Agricultural Equipment:
Hydraulic pumps are also commonly used in agricultural equipment, such as tractors and combine harvesters.
Aerospace Industry:
Hydraulic pumps are even used in the aerospace industry for various purposes, such as aircraft brakes and landing gear.
Packaging and Shipping
|
Packaging |
Wooden box, PE film |
|
Transportation methods |
Road transport, rail transport, sea transport, air transport |
