Products Description
| Item | Disc Geroler Motors |
| Mode | 4000 Series |
| Direction Of Rotation | Reversible |
| Fastening | 4 Bolts Standard Type |
| Flange | SAE FLANGE |
| Charlynn Code | 109-1339-006 |
| Highlight | Gerotor Hydraulic Motor 109-1339-006, char lynn hydraulic motor 109-1339-006, 4000 Series Gerotor Hydraulic Motor |
Product details
| PRODUCT | MOTOR |
| SERIES | 4000 SERIES |
| DISPLACEMENT | 393.9 CM3/R [24.04 IN3/R] |
| MOUNTING TYPE | STANDARD, 4 BOLT; 127.00 [5.000] PILOT DIA.14.27 [.562] DIA. HOLES ON 161.92 [6.375] DIA. BOLT CIRCLE. (SAE C) |
| OUTPUT SHAFT | 40.00 [1.575] DIA. STRAIGHT WITH M12 X 1.75-6H THREAD, 7.955 [.3132] X 11.979 [.4716] WIDE X 69.98 [2.755] STRAIGHT KEY |
| PORTS | 1.0625-12 UN-2B SAE O-RING PORTS - STAGGERED PORTS |
| FLOW OPTIONS | .4375-20 UNF-2B SAE O-RING PORT WITH CHECK VALVE |
Core Selling Points
- Original factory-level compatible design, perfectly matching the original specifications of the Char-Lynn 4000 Series, allowing direct replacement without modification.
- Gerotor structure, featuring large output torque and high volumetric efficiency, suitable for high-intensity operation scenarios.
- Aftermarket cost-effective solution, retaining core OEM performance with more advantageous costs.
Applicable Scenarios
- Construction machinery: slewing mechanisms and travel drive systems of excavators, loaders, and cranes.
- Agricultural machinery: hydraulic actuators of tractors and combine harvesters.
- Industrial equipment: conveyor belts, hydraulic workstations, and hydraulic power units for mining machinery.
- Special equipment: marine deck machinery, port lifting equipment, and wind power hydraulic systems.
Product Advantages
- Strong compatibility: Produced strictly in accordance with OEM size and performance standards, the installation interface and oil circuit design are completely consistent with the original parts, allowing direct replacement for immediate use.
- Outstanding durability: Adopting high-strength alloy gears and wear-resistant seals, it is impact-resistant and corrosion-resistant, extending the service life.
- High power efficiency: The internal meshing gear structure has high meshing precision and low energy loss, maintaining stable output under both high and low pressure working conditions.
- Cost-effective choice: Compared with new original factory products, the aftermarket version significantly reduces procurement costs and equipment maintenance budgets while ensuring core performance.
