Char-Lynn 101-1001-009 Hydraulic Motor With 4-Bolt Flange, 2.8 In³/R Displacement & 1/2 Inch NPTF Ports

Item	Hydraulic Motor
Type	Orbit Motor
Direction	Left And Right
OEM #	Char-lynn 101-1001-009
Speed	Rpm
Displacement	46cc
Port Size	1/2 Inch NPTF
Shaft Size	1 Inch Dia X 1-3/4 Inch Length
Highlight	cycloid hydraulic motor, hydraulic rotary motor

Char-Lynn 101-1001-009 is a H-series gerotor hydraulic motor produced by the Eaton Char-Lynn brand, belonging to the industry-classic H Series products. This motor adopts the time-tested Spool Valve Technology and advanced Gerotor design, providing a displacement of 2.8 cubic inches per revolution, equipped with a 4-bolt square mounting flange and 1/2 inch NPTF dry-seal pipe thread ports. It is an ideal drive solution for various medium-load applications.

This product is renowned for its compact structure, reliable performance, and wide application adaptability. It is an ideal choice for direct drive applications, which can effectively replace traditional mechanical transmission components and simplify equipment design.

1. Time-tested Char-Lynn cycloidal technology

• Industry classic: The Char-Lynn H series is a benchmark product in the field of cycloidal hydraulic motors, validated by decades of market presence
• Three-component design: Only 3 moving parts (cycloidal rotor, drive shaft, output shaft), with a simple structure and high reliability
• Optimized drive angle: The optimized drive operating angle reduces wear and extends service life

2. Slide valve distribution technology

• Mature and reliable: Adopts industry-verified slide valve distribution technology for sensitive response
• Three-zone pressure design: Independent pressure control for the oil inlet zone, oil return zone, and housing zone, resulting in higher efficiency
• High starting torque: Low starting pressure, with starting torque reaching over 90% of the theoretical value

3. Compact and efficient power density

• Small but powerful: Weighing only 10.5 lbs, it provides 650 in-lbs of torque and 12 GPM flow capacity
• Direct drive capability: Can directly drive working mechanisms without the need for reduction devices, simplifying equipment design

4. Standardized interface configuration

• 4-bolt flange: SAE standard Type B flange, with a mounting hole distance of φ82.55 mm, offering strong versatility
• 1-inch straight shaft: Standard shaft diameter, compatible with various couplings and hubs
• 1/2" NPTF oil port: American standard dry-seal pipe thread, ensuring reliable sealing and easy availability of accessories
