Technical parameters
| Item | Hydraulic Motor |
| OEM # | BMER-2-750-FS-G2-S-R |
| Manufacturer | XLF Hydraulid |
| Displacement | 750 Ml/r |
| Mounting Flange | 6-hole Wheel Flange |
| Shaft Type | Straight |
| Highlight | lsht orbit hydraulic motor, 750cc orbit hydraulic motor, 750cc lsht motor |
Product Overview
BMER-2-750-FS-G2-S-R is a high-performance large-displacement LSHT cycloidal hydraulic motor in the BMER-2 series. It features 745 cm³/rev displacement, 100 RPM rated speed and counterclockwise (CCW) rotation, adopting advanced Rolortorc™ Geroler technology and high-speed oil distribution. Equipped with a 6-bolt magneto mounting flange, 1.25-inch keyway shaft and SAE #10 ports, it provides high torque output, excellent low-speed stability and strong load-bearing capacity, ideal for agricultural machinery, construction machinery, material handling and industrial equipment.
Core Features
Unique 6-Bolt Magneto Mounting Flange
Equipped with a dedicated 6-bolt magneto mounting flange, it ensures precise positioning and secure fixation, making it ideal for combine harvesters, balers, and heavy industrial equipment. It provides high-rigidity mounting connection, strong torque resistance, and accurate alignment, minimizing installation errors and extending the motor's service life.
1.25-Inch Keyway Output Shaft
The 1.25-inch (31.75mm) keyway output shaft, paired with a 5/16-inch flat key, enables reliable transmission of up to 1050 N·m continuous torque. Its keyway design ensures stable power delivery, facilitates seamless mating with hubs, sprockets, and couplings, and offers high compatibility with heavy-duty drive components.
Large Displacement & High Torque Output
Boasting a large displacement of 745 ml/r, the motor generates up to 1050 N·m continuous torque and 1180 N·m intermittent torque. As a typical LSHT (low-speed high-torque) motor, it delivers stable, high torque at a rated speed of 100 RPM, effectively meeting the demands of heavy-load startup and precise control.
Main Specificaion
| Factory Location | China |
| Port Size | #10 SAE (5/8") |
| Shaft Size | 1.25" Bore x 5/16" Key |
| Shaft Type | Keyed |
| Port Location | Side Ported |
| Flow Rating | 14 |
| Pressure Rating | 2973 |
| Displacement | 118 |
| Max Speed | 360 |
| Service Parts | BMER-2 Seal Kit (Small Shafts), BMER-2 Seal Kit (Large Shafts) |
| Country of Manufacture | China |
| Height | 5.38 |
| Length | 4.68 |
| Width | 5.76 |
| Weight | 27.45 |
