95 Cc Orbit Hydraulic Motor | 1 1/4" Tapered Shaft Wheel Mount | Parker TF0195LS080XXXX Alternative

Single	Wheel Motor
Type	High Pressure, Without Drain
Direction	Unti-clockwise
Speed	330/425RPM
Torque	530/600/750NM
Mounting	Wheel Mounting
Port	SAE O-ring
Shaft	1 1/4'' Tapered
Highlight	195 Cc Orbit Hydraulic Motor, 425RPM Orbit Hydraulic Motor, 750NM Orbit Hydraulic Motor

This product is a high-performance cycloidal hydraulic motor with a displacement of 95 ml/r. It adopts an 1 1/4-inch (approximately 31.75mm) 1:8 tapered output shaft and a wheel-mounted flange design, optimized specifically for mobile machinery applications requiring compact wheel-side drives. As a direct replacement model for the Parker TF0195LS080XXXX series, it perfectly matches the original factory installation interfaces and performance parameters, providing a reliable and cost-effective hydraulic power solution for skid steer loader attachments, small mobile equipment, and industrial wheel drives.

1. Direct replacement for Parker TF0195 series
• Perfect interchangeability: It has exactly the same mounting flange, 1 1/4" tapered shaft size and oil port position as the original Parker TF0195LS080XXXX series, enabling direct replacement without any modifications.
• Consistent performance parameters: Key performance indicators (displacement, torque, pressure level) are highly matched with the original model, ensuring that the equipment operates unchanged after replacement.
2. 95ml medium displacement design
• Balanced torque output: The 95 ml/r displacement achieves an ideal balance between compact size and sufficient torque, providing a continuous torque of approximately 150-180 N·m, which can drive small and medium-sized walking equipment and various accessories.
• Medium speed range: Suitable for stable operation within the speed range of 100-800 rpm, meeting the speed requirements of most travel drives.
3. 1 1/4" 1:8 tapered output shaft
• High-rigidity torque transmission: Adopting a standard 1:8 taper shaft design, locked by a shaft end nut, it provides gap-free and high-rigidity torque transmission, especially suitable for direct installation of hubs or sprockets.
• High load-carrying capacity: The tapered shaft design can withstand large radial and axial loads, adapting to the force characteristics of walking equipment.
4. Wheel-mounted flange design
• Compact wheel-end drive: The offset mounting flange allows the hub to be directly mounted on the motor housing, so that the radial load acts between the two bearings, maximizing the bearing capacity.
• Saving installation space: No external support bearings are required, and the motor is directly embedded in the hub, greatly simplifying the axle design.

This 95cc conical shaft wheel motor is widely used in the following equipment:

1. Skid steer loader accessories
Brush drive: rotational drive for brushes in cleaning vehicles and road sweepers

Auger drive: used in digging and tree-planting drilling operations

Small milling machines: used in road repair operations

2. Small walking equipment
Handheld rollers: travel drive system

Small forklifts/pallet trucks: wheel-side drive units

Scissor-type aerial work platforms: travel drive motors

3. Agricultural machinery
Small harvesters: travel drive

Lawn mowers: drive for self-propelled lawn mowers

Sprayers: drive for pesticide pumps
