250cc 500230W3821AAAAA White Drive Products Hydraulic Motor | Fits Dixie Chopper Mowers Wheel

Type	High Torque Hydraulic Motor
Max Speed	290rpm-350rpm
Displacement	250cc
Application	Sweepers,mowers
Torque	700N.M-790N.M
Flow	75--95 L/MIN
Pressure	20.5mpa-24mpa
Highlight	250cc white drive products hydraulic motor, mowers white drive products hydraulic motor

500230W3821AAAAA is a 250cc displacement gerotor hydraulic motor produced by White Drive Products. It is an original equipment and replacement part for the travel drive system of Dixie Chopper zero-turn mowers -. This model is optimized for wheel drive applications in zero-turn mowers, providing the equipment with strong, smooth, and reliable travel power, ensuring precise control and excellent performance in mowing operations on complex terrains and with frequent starts and stops.

1. Optimized specifically for Dixie Chopper lawn mowers
• Original equipment replacement standard: As an original specification motor配套 by White Drive Products for Dixie Chopper, 500230W3821AAAAA perfectly matches the installation interfaces and performance requirements of various zero-turn lawn mower models of Dixie Chopper.
• Direct installation design: The installation flange, output shaft size and oil port position are exactly the same as those of the original Dixie Chopper vehicle, allowing for quick replacement without any modifications

2. 250cc large displacement and high torque output
• Powerful driving force: The 250 cm³/rev displacement provides a continuous torque of up to 450-540 N·m, which can easily drive the lawn mower to travel on slopes, dense grass and complex terrains.
• Low-speed and high-torque characteristics: Typical LSHT design, which can output stable and strong torque at extremely low speeds, meeting the needs of precise control and in-place steering of zero-turn lawn mowers.
3. Structural design optimized for walking drive
• Wheel-mounted flange: An offset mounting flange is adopted, allowing the wheel hub to be directly mounted on the motor housing, so that the radial load acts between the two heavy-duty bearings, maximizing the bearing capacity.
• High-load bearing system: The output shaft is supported by heavy-duty tapered roller bearings, which can withstand the huge radial and axial loads generated by the lawn mower during high-speed driving and steering.
• High-strength cast iron housing: The sturdy housing design can withstand the impact and vibration during the operation of zero-turn lawn mowers.
