Hydraulic 2000 Series Char-Lynn Motor With Brake Valve | 2-400 AC4+V2L17 A6 60

Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. is one of the leading manufacturers and suppliers of hydraulic 2000 series char-lynn motor with brake valve | 2-400 ac4+v2l17 a6 60 in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Also, OEM&ODM service is available.

Product	Disc Valve Hydraulic Motor
Replace	Charlynn
Apply To	Rock Drills Machines
Displacement	400ml/r
Flange	4 Hole, Rhomb
Shaft	Cone-shaft 31.75mm
Max Flow	75 L/min
Max Speed	280 Rpm
Highlight	2000 series char lynn motor, 2000 series char lynn motor hydraulic, CE 2000 series char lynn motor

The Eaton Char-Lynn 2000 series hydraulic motors are industry benchmarks in the field of gerotor motors, renowned worldwide for their compact structure, extremely high power density, and excellent reliability. This model, 2-400 AC4+V2L17 A6 60, is a special configuration disc valve motor with an integrated brake valve group, featuring a displacement of 400 cc/rev. It integrates powerful rotational power output with precise load holding/braking functions, making it particularly suitable for demanding applications that require smooth starting, stopping, and hovering holding under high pressure, such as lifting, traction, and travel drives.

1. Integrated Brake/Valve Group (Brake Valve)

• The model code "V2L17" indicates that this motor is integrated with a specific valve group configuration, which usually includes an overload relief valve (cross relief valve) and an anti-cavitation valve.
• Functional advantages: When the load suddenly stops or an external force tries to reverse-drag the motor, the integrated valve group can lock the hydraulic oil, provide smooth deceleration and reliable static holding braking, prevent the load from falling or the equipment from getting out of control, and greatly improve operational safety.
• Simplified system: It eliminates the need to separately install a balance valve or brake valve in the external pipeline, making the hydraulic system more compact and reducing potential leakage points.

2. Efficient Disc Valve Distribution

• As a standard configuration of the 2000 series, the disc valve distribution technology provides excellent low-speed stability and high starting torque efficiency.
• It can maintain smooth operation throughout the entire speed range, even avoiding jamming during heavy-load startup.

3. Robust Load-Bearing Structure

• The output shaft is supported by heavy-duty tapered roller bearings, which can withstand extremely high radial and axial loads, which is crucial for applications that directly drive reels or wheels.
• High-strength cast iron housing and internal components ensure a long service life under harsh working conditions.

Thanks to its large displacement and integrated brake valve group, this model is particularly suitable for:

• Lifting and traction: hydraulic winches, crane slewing and luffing mechanisms, cable laying equipment.
• Walking machinery: heavy industrial vehicles, travel drives of large agricultural machinery (such as combine harvesters), drill feed systems.
• Material handling: wheel drive or working devices of telehandlers, reach stackers, and heavy forklifts.
• Forestry and mining: skidding winches, rotation of wood grabs, mining conveyor drives.
