GFT110 T3 1316 Travel Gearbox Reducer R916560103
Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. is one of the leading manufacturers and suppliers of gft110 t3 1316 travel gearbox reducer r916560103 in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Also, OEM&ODM service is available.
Specifications
| Type | GFT110 T3 1316 Travel Reduction Gear (R916560103, Ratio i=114.8) |
| Brand | XLF Hydraulic |
| Max Output Torque Range | 92000 N·m ~ 110000 N·m |
| Rated Working Pressure | 35 MPa |
| Peak Pressure | 42 MPa |
| Mount Flange | 1316 Standard Flange (Fit A6VE160 / A2FE180 Hydraulic Motor) |
| Port Size | Brake Release Port: G1/2", Drain Port: G3/8", Oil Fill/Drain Port: G1" |
| Built-in Parts | 3-stage planetary gear set, integrated multi-disc wet spring brake, heavy-duty tapered roller bearing, multi-layer sealing assembly |
| Recommended Oil | ISO VG220 EP Industrial Gear Oil |
Product Overview
Product Overview For R916560103 GFT110 T3 1316 Travel Reduction Gearbox Reducer
R916560103 GFT110 T3 1316 planetary final drive gearbox is a 3-stage heavy-duty shell rotating travel reducer specially designed for heavy waste compactors, full OEM interchange replacement matching original Rexroth hydraulic drive assemblies. Equipped with standard 1316 motor mounting flange, perfectly compatible with A6VE160 & A2FE180 hydraulic motors and multi-layer composite anti-leak sealing system.
Carburized hardened planetary gear sets and high-strength ductile iron housing deliver massive low-speed high torque for waste compaction, steep ramp climbing and continuous heavy-load compaction operation, supporting plug-and-play direct replacement of the original reducer without any equipment modification.
Rated working pressure 350 bar, peak pressure up to 420 bar, stable continuous torque output under long-duration heavy compaction loads. Shock-resistant robust gearbox structure adapts to severe dusty, garbage and harsh outdoor working environments.
Integrated multi-disc wet spring parking brake and oversized heavy-duty output bearings perfectly match the original Rexroth hydraulic motors with no extra adapters required, a reliable, cost-effective wheel-side final drive gearbox for large waste compactor machinery.
Core Advantages
R916560103 GFT110 T3 1316 is a high-performance planetary gearbox reducer, featuring a 3-stage shell rotating planetary final drive, fully interchangeable with original Rexroth units for heavy waste compactors. Hardened planetary gears and heavy-duty tapered roller bearings deliver stable ultra-high low-speed torque for compaction and steep climbing loads.
This professional gearbox reducer directly matches A6VE160/A2FE180 motors via standard 1316 flange without extra adapters, ideal for landfill waste compaction equipment. 1:1 OEM mounting dimensions support plug-and-play swap and cut maintenance downtime.
Rated 350 bar working pressure with 420 bar peak pressure enables this heavy-duty gearbox reducer to sustain continuous heavy-load operation. Reinforced alloy gears and multi-layer sealing resist impact, oil leaks and dust ingress in harsh landfill sites.
Stable performance from -20℃ to +80℃. Optimized 3-stage planetary design hits above 93% mechanical efficiency with low noise, making it a cost-effective gearbox reducer replacement for Rexroth GFT series travel reducers.
Q: Which machines fit this gearbox reducer?
A: R916560103 GFT110 T3 1316 3-stage planetary travel gearbox reducer is specially matched for heavy-duty waste landfill compactors.
Q: Direct OEM interchangeable?
A: Yes. The 1316 motor mounting flange, bolt hole layout, output connection structure and overall dimensions are 1:1 identical to original Rexroth units, supporting plug-and-play installation without equipment modification.
Q: Key technical specs?
A: Rated working pressure 350 bar, peak pressure 420 bar; continuous rated output torque 92000 N·m, peak short-term torque 110000 N·m. Adopts 3-stage carburized hard-tooth planetary transmission structure.
Q: Compatible with original hydraulic motors?
A: Perfectly fits Rexroth A6VE160 and A2FE180 hydraulic motors via standard 1316 flange, directly compatible with original factory walking hydraulic circuits without transition adapters.
Q: Stable compaction performance?
A: Precision carburized and finely ground alloy planetary gears reduce friction, vibration and wear, providing steady low-speed high torque to cope with dusty, garbage-filled severe landfill working environments.
Q: Heavy-duty upgraded options available?
A: Optional reinforced thickened gear sets, multi-layer composite anti-leak sealing components and oversized heavy-duty tapered roller bearings for frequent overload and harsh working scenarios.
Q: Recommended lubricant & maintenance cycle?
A: ISO VG220 EP extreme pressure industrial gear oil. Inspect oil level and sealing parts daily; fully replace gear oil every 1000 working hours under heavy dust environment.
Q: Troubleshoot leakage & overheating?
A: Retighten mounting bolts for slight oil seepage; replace full sealing kit for severe leakage. Overheating is usually caused by deteriorated lubricant, insufficient oil volume or worn gear components. Follow standard maintenance procedures, do not disassemble privately.
Q: Warranty terms?
A: 12-month factory warranty. Free technical support and free replacement parts for non-human damage under standard operating conditions.
1. Basic Identification Data
| Parameter Item | Specification Value |
|---|---|
| Original Material Number | R916631864 |
| Complete Model Code | GFT65 T2 1006 i=55.4 |
| Product Series | HYDROTRAC GFT Planetary Travel Final Drive |
| Reduction Stage | T2 Two-stage planetary gear reduction |
| Reduction Ratio | i=55.4 |
| Flange Version Code | 1006 (Custom OEM mounting flange variant) |
| Original Manufacturer | Bosch Rexroth |
| Aftermarket Equivalent Brand | XLF Hydraulic |
2. Torque & Rotation Performance
| Parameter Item | Specification Value |
|---|---|
| Rated Continuous Output Torque | 65000 N·m |
| Max Instantaneous Peak Torque | 128000 N·m |
| Maximum Allowable Input Speed | 3500 rpm |
| Normal Output Speed Range | 0 ~ 65 rpm |
| Overall Transmission Efficiency (Rated Load) | ≥92% |
3. Hydraulic System Matching Parameters
| Parameter Item | Specification Value |
|---|---|
| Rated Continuous Working Pressure | 320 bar (32 MPa) |
| Short-Term Maximum Peak Pressure | 350 bar (35 MPa) |
| Max Permissible Housing Back Pressure | ≤10 bar |
| Standard Hydraulic Port Thread Size | G1/2 |
| Compatible Matching Hydraulic Motors | A6VE160 / A2FE180 Series |
4. Integrated Parking Brake Technical Data
| Parameter Item | Specification Value |
|---|---|
| Brake Type | Built-in Wet Multi-disc Static Parking Brake |
| Minimum Brake Release Pressure | 18 ~ 22 bar |
| Locking Mechanism | Spring-applied, Hydraulic Release (Fail-safe design) |
5. Mechanical Structure, Material & Sealing
| Parameter Item | Specification Value |
|---|---|
| Main Support Bearing | Heavy-duty Tapered Roller Bearing |
| Gear Material | Carburized & Quenched Alloy Steel, Precision Ground |
| Standard Sealing Assembly | Duo-cone Floating Oil Seal |
| Housing Material | Thick High-strength Cast Alloy Housing |
| Standard Built-in Components | Planetary Gear Set, Parking Brake Unit, Heavy-duty Main Bearings, Floating Seal Kit |
6. Lubrication, Weight & Ambient Operation
| Parameter Item | Specification Value |
|---|---|
| Gear Oil Filling Capacity | 8.5 L |
| Recommended Lubricant Grade | ISO VG220 / VG320 Heavy-duty Industrial Gear Oil |
| Net Weight (Excluding Hydraulic Motor) | 265 kg |
| Continuous Operating Temperature Range | -20 ℃ ~ +85 ℃ |
7. Installation & Compatible Machinery
| Parameter Item | Specification Value |
|---|---|
| Standard Mounting Flange | GFT65 T2 1006 OEM Standard Flange, 1:1 Interchangeable |
| Installation Feature | Plug-and-play replacement, no chassis modification required |
| Applicable Construction Equipment | Crawler Excavator, Rotary Drilling Rig, Asphalt Milling Machine, Crawler Transporter, Mining Crawler Machinery |
8. Maintenance & Warranty Standard
| Parameter Item | Specification Value |
|---|---|
| Initial Gear Oil Change Interval | 500 Working Hours |
| Routine Full Oil Replacement Cycle | 2000 Working Hours |
| Aftermarket Factory Warranty Term | 12-month Full Coverage Warranty |
