BK2 Series Hydraulic Motor Brake System – 300 Bar Static Torque, 410-450 Nm

Type	Hydraulic Motor Brake
Brand	XLF Hydraulic
Model No.	BK2-1-430-A-A
Min Static Torque	410 - 450 Nm
Min Opening Pressure	1.7 - 2.3 MPa
Max Opening Pressure	30 MPa
Min Oil Qty For Brake Releasing	7 - 8 Cm3
Oil Volume	50 - 120 Cm3
Max Pressure In Drain Space	0.05 MPa
Application	Cranes, Construction
Highlight	bk2-1-430-a-a motor orbit hydraulic, 300 bar motor orbit hydraulic

The BK2 series hydraulic motor braking system is a normally closed wet multi-disc brake specially designed for heavy-duty mechanical equipment, which adopts the working principle of high-strength spring braking and hydraulic release. Represented by the model BK2-1-430-A-A, it has a maximum opening pressure of 300 bar and a minimum static braking torque of 410-450 Nm, and can provide reliable safety braking protection for equipment such as walking machinery, cranes, and winches. This braking system can be directly matched and installed with cycloidal hydraulic motors of BMP, BMR, BMS and other series, making it an ideal choice for realizing static braking function in hydraulic drive systems.

1. High-performance wet multi-disc design

• Spring-applied/hydraulic-released: Adopting a normally closed design, the high-strength spring automatically applies braking force when there is no hydraulic pressure, ensuring the safety of equipment parking; the brake is released through hydraulic pressure, with precise and controllable operation.
• High-friction material: Using specially formulated friction plates and high-strength springs, it provides a reliable static braking torque of 410-450 Nm, meeting the braking requirements of heavy-duty equipment.
• Long service life and low noise: The wet design allows the friction plates to work in oil, with excellent heat dissipation performance, avoiding thermal recession, while having low operating noise and high braking reliability.

2. Flexible interface design

• 4 oil drain ports: Multiple oil drain port positions are provided, which can be flexibly selected according to the installation space and pipeline layout to adapt to different working conditions.
• Compact structure: The overall design is compact, requiring low installation space, and is easy to integrate into various mechanical equipment.
• 25mm standard shaft diameter: Both input and output shafts are 25mm cylindrical shafts, equipped with standard flat keys, perfectly matching mainstream hydraulic motors.

3. Perfect compatibility with mainstream hydraulic motors

• Preferential matching series: Can be directly used with BMP (MP), BMR (MR), BMS (MS) and other series of gerotor hydraulic motors.
• International brand compatibility: Suitable for the braking needs of mainstream hydraulic motors such as Danfoss OMP/OMR/OMS, Eaton Char-Lynn 2000 series, M+S MP/MR/MS.

1. Engineering and Construction Machinery
Cranes, construction machinery

Road machinery and vehicles

Loaders, excavators

Road rollers, bulldozers

2. Material Handling Equipment
Forklifts, telehandlers

Handling machinery

Warehousing equipment

3. Agricultural and Forestry Machinery
Agricultural machinery (large sprayers, harvesters)

Forestry machinery (skidders)

Woodworking machinery
