XLF-PV2R PV2R Series Hydraulic Double Vane Pump Oil Plunger Pump PV2R1-25-F-RBA-43 PV2R1 PV2R2 PV2R3 PV2R4

XLF-PV2R PV2R Series Hydraulic Double Vane Pump Oil Plunger Pump PV2R1-25-F-RBA-43 PV2R1 PV2R2 PV2R3 PV2R4

Key attributes

Industry-specific attributes

Warranty
1 Year
Displacement
Other
Pump Type
Vane Pump

Other attributes

Showroom Location
None
Place of Origin
Zhejiang, China
Weight
8
Pressure
/
Structure
/
Power
/
Dimension(L*W*H)
20*15*12cm
Maximum Flow Rate
1800r/min

Quantity:
Availability:





Inquire Add to Basket

Model:
PV2R
Brand:
XLF
Code:
VP0016

Product Description

Product Description

Installation Dimensions

平键轴Straight key shaft
型号 Series	轴伸代号 Shaft code	A	B	C	中D	E	F键宽长 F Key widthlength
20VQ、 SQP1	1	59	9.53	12.1	22.23/22.20	24.5/24.4	4.76*32
25VQ、2520VQ SQP2、SQP21	1	59	9.53	11.1	22.23/22.20	24.5/24.4	4.76*32
25VQ、2520VQ SQP2、SQP21	86	78	9.53	11.1	25.37/25.35	28.3/28.1	6.36*50.8
35VQ、35※VQ SQP3、SQP3※	1	73.2	9.53	11.1	31.75/31.70	35.36/35.10	7.94*38.1
35VQ、35※VQ SQP3、SQP3※	86	86	9.53	11.1	34.90/34.87	38.6/38.3	7.94*54
45VQ、45※VQ SQP4、SQP4※	1	62	12.7	14.22	31.75/31.70	35.36/35.10	7.94*28.5
45VQ、45※VQ SQP4、SQP4※	86	87.4	12.7	14.22	38.07/38.05	42.4/42.1	9.54*50.8

花键轴Spline shaft
型号 Model	轴伸代号 Shaft code	A	B	C	D	E	花键数据（见下表） Spline data (See table below)
20VQ	151	41.1	9.53	11.1	3.9	27.8	A
25VQ、2520VQ	11	44.5	9.53	11.1	3.9	27.8	A
35VQ、35※VQ	11	58.7	9.53	11.1	6.35	35.1	C
45VQ、45※VQ	11	61.9	12.7	14.3	9.7	39.6	C

花键轴数据表(渐开线花键)Spline data table (involute spline)
花键数据标记 Spline data reference	齿数 Number of teeth	径节 Pitch	大径 Major diameter	成形直径 Form diameter	小径 Minor diameter	平齿根配合 Flat root fit
A	13	16/32	22.17/22.15	19.03	18.63/18.35	大径配合 Major diameter fit
C	14	12月24日	31.70/31.67	27.2	26.99/26.64	大径配合 Major diameter fit

Technical Data

产品型号 Model	量高压力允许转通理论排量 Max pressure(MPa) Speed (timin)						要功功率 Input power (kW)
产品型号 Model	Displacement (mLIr)	高压用特定油 Special oil	抗磨液压油 Antiwear ol	普通液压油 Common ol	是低 Min	最高 Max	要功功率 Input power (kW)
PV2R1-4	4.3	21	17.5	16	750	1800	2.1
PV2R1-6	6.5						3.2
PV2R1-8	8.5						4.5
PV2R1-10	10.8						5.4
PV2R1-12	12.8						6.1
PV2R1-14	14.5						6.9
PV2R1-17	16.2						7.9
PV2R1-19	20.1						9.6
PV2R1-23	22.5						10.5
PV2R1-25	25.3						12.5
PV2R1-28	29.6						14
PV2R1-31	32.3	16	16				15.5
PV2R2-26	25.3	21	17.5	54	600	1800	11.7
PV2R2-33	32.3						15.5
PV2R2-41	39.8						18.9
PV2R2-47	49.8						23.2
PV2R2-53	51.5						24
PV2R2-59	55.8						24.9
PV2R2-65	63.7						29.4
PV2R2-70	70.3	16				1200	31.6
PV2R2-79	78.1						35.7
PV2R2-85	82.7						37.5
PV2R3-52	51.5	21	17.5	14	600	1800	23.2
PV2R3-60	63.7						29.4
PV2R3-66	66.6						34.2
PV2R3-76	75.5						37.7
PV2R3-94	89.5						41.2
PV2R3-116	118	16	16				50
PV2R3-125	122.2					1200	59.9
PV2R3-136	136					1200	66.7
注：1.公称排量“4”、“6”、“8“泵，压力超过16MPa佳用时，转速应超过1450rimin。 2.在高转速下使用大排量单系及相应的双泵时，应减少暖入口负压。 3.使用合或浦压油及含水浦压浦时，是高转速理制在1200rlmin。 4.对于特别要求低隆音的场合，建议工作特速选用1000r/min。 5.幢声值是在P=14MPa.n=1200rimin的工况下。 6.要动功率是在P=16MPa、ne1500r/min的工况下。 Note: 1. When pressure of pumps exceeds 16MiPa, with displacement of"4* "g* "8".speeds should be more than 1450r/min. 2. Reduce the negative pressure of the iniet when the single pumps or double pumps with large displacement at high speed. 3. In use of synthetic hydrauic fiuids and water containing hydrauic fiuids, äimit the max speed at 1200rimin. 4. Spood at 1000rimin is suggested on cccasions with iower noise strietly required. 5. Nolsinets is available in working conditions of 14MPa and 1200rimin. 6. Input power is availlabie in working conditions of 16MPa and 1500rimin.

To protect your rights please read the following carefully Pump Start-up Procedure Preparation Prior to Start-up The reservoir and circuit should be clean and free of dirt and debris prior to filling with fluid. Circuit Cleanup The reservoir should be charged with filtered hydraulic fluid. The fluid level should be sufficient to prevent vortexing at the suction connection to the pump inlet. It is good practice to clean the system by flushing and filtering, using an external slave pump. Filling Pump and Removing Air If the pump is mounted above the fluid level, it should be filled with fluid through the outlet port. If the pump is mounted below the fluid level, the pump outlet fitting (or other downstream fitting or plug) can be loosened to allow fluid to displace the air. It may be necessary to loosen the fill cap on the reservoir to allow the fluid to flow freely. When a solid stream of fluid with no observed air begins to drain through the loosened fitting, the fitting should be retightened. An air bleed valve in the outlet circuit is also recommended to remove trapped air. If such a device is used, the pump should be filled with fluid before start-up. In some cases, it may be possible to prime the pump by running the engine starter for five to ten seconds with the throttle and/or ignition switch in the "off" position. It will be necessary to loosen a fitting or plug in the pump outlet to allow air to escape. Pump Start-up All controls should be placed in the neutral position so the pump is unloaded when started. Start the engine and run at low idle. Once the pump is started, it should prime and pump within a few seconds. If it does not, make sure there are no restrictions between the reservoir and the inlet to the pump, and that there are no air leaks in the inlet line and connections. Also, make sure that trapped air can escape from the outlet. Run at low engine idle for approximately five minutes. Then, while observing the reservoir fluid level, operate the implements. Extend all actuators to maximum safe limits to completely fill the system with fluid. Do not run with the fluid level below the "low" limit. Add fluid to the reservoir to bring the fluid to the proper fill level.
