ERR ERL Series Hydraulic Pump Hydraulic Pump Sauer Danfoss Hydraulic Pump Variable Plunger Pump
Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. is one of the leading manufacturers and suppliers of err erl series hydraulic pump hydraulic pump sauer danfoss hydraulic pump variable plunger pump in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Also, OEM&ODM service is available.
Specifications
| Type | Variable Displacement Axial Piston Pump for Open Circuit (R = CW / Clockwise Rotation; L = CCW / Counter-Clockwise Rotation) |
| Brand | XLF Hydraulic |
| Displacement | 130 / 145 / 193 / 260 cc/rev (multiple displacement options) |
| Rated Working Pressure | 350 bar (continuous operating pressure) |
| FlangeIntermittent Peak Pressure | 400 bar |
| Mount Flange | SAE standard open-loop flange (SAE J743 equivalent, matching model codes D4/E4/EA) |
| Port Size | SAE standard O-ring ports (size varies by displacement; e.g., 1 1/16-12UN, 1 5/16-12UN for different models) |
| Built-in Parts | Integral charge pump + pressure relief valve + optional control valve assembly (TPSN/TPE5/ENSN/TPE2, etc., depending on configuration) |
| Recommended Oil | ISO VG32 / VG46 anti-wear hydraulic oil (compatible with standard mineral hydraulic fluids) |
Product Overview
Model ERR100 / ERR130 / ERR147 (ER-R Right-hand / ER-L Left-hand) are heavy-duty variable displacement axial piston pumps designed for open hydraulic circuits, belonging to the ERR & ERL Series. This product line adopts dedicated internal coding systems to distinguish various specification variants. Featuring the mature swash plate variable displacement technology and wear-resistant valve plate structure that effectively prevents cylinder block deflection, these pumps serve as ideal direct aftermarket replacements for original OEM pumps with identical specifications of the ERR/ERL platform.
The ERR & ERL Series are high-performance, high-efficiency piston pumps. They deliver stable large flow and high-pressure output within a compact housing, with 280 bar continuous working pressure and 300 bar intermittent peak pressure (320 bar maximum shock pressure). Operating reliably in harsh working environments including open-pit mining, construction cranes, concrete delivery and road construction projects, the pumps exhibit excellent pressure resistance and long-term operational durability. They are the preferred core hydraulic power units for heavy-duty machinery such as small and medium excavators, roadheaders, crawler cranes, concrete mixer trucks, road rollers and drilling rigs. Equipped with standard SAE heavy-duty mounting specifications and multi-bolt fixed flange layout, the full series can withstand frequent heavy impact loads and continuous mechanical vibration, fully adapting to the rigorous operating conditions of diverse mobile machinery and equipment.
This pump series supports customized structural configurations, including shaftless and semi-shaftless designs for integrated transmission. These tailored versions are specially developed to match customer-assembled planetary gear reducers and integrated hydraulic transmission assemblies. The customized pumps remove the traditional independent output shaft, and connect directly with the gear sets of peripheral drive systems via custom spline sleeves and dedicated tooth profiles. They are perfectly suited for hydraulic systems with limited installation space, as well as mechanical equipment adopting integrated modular and lightweight design concepts. This range is especially applicable to e-Hydraulic power module solutions for modern electrified construction machinery.
Core Advantages
Integrated Structure Design - An Ideal Choice For Integrated Drive & Electrified Systems
Danfoss ERR & ERL Series Hydraulic Piston Pump ERR100 / ERR130 / ERR147 (ER-R Right-hand / ER-L Left-hand) adopts optimized integrated structure design, which is a dedicated configuration for integrated drive and electrified hydraulic systems:
Integrated connecting structure: Custom spline and shaft end design are adopted. External radial loads are shared by the matching motor or reducer assembly on the user's equipment; Direct integration with gear reducers & drive motors: The pump can be directly mounted to planetary gearboxes or Danfoss Editron drive motor assemblies without additional support bearings or couplings, perfectly matching the eHydraulic power module for electrified machinery; Compact axial dimension: The streamlined cast iron pump body greatly shortens the overall axial length, making it particularly suitable for equipment with extremely limited installation space; Easy installation: Standard SAE heavy-duty mounting dimensions and multi-bolt fixed flange layout enable seamless matching with user equipment and ensure excellent concentricity and stable operation during long-term running.
ERR & ERL Series - High Performance Open Circuit Axial Piston Hydraulic Pump
The Danfoss ERR & ERL Series stands for premium high-performance axial piston hydraulic pumps for open circuits in Danfoss' Series 45 product lineup:
High power density: Delivers stable large flow and high-pressure output within a compact housing; Advanced swash plate & cylinder block assembly: Equipped with dual servo piston controlled swash plate and polymer-coated journal bearings, plus reinforced 9-piston cylinder block structure, it achieves higher mechanical efficiency and strong resistance to shock and continuous mechanical vibration; Bi-metallic valve plate flow distribution technology: The proprietary bi-metallic valve plate effectively prevents cylinder block tilting, features automatic wear compensation, maintains excellent volumetric efficiency in long-term operation and reduces internal pressure loss and operating noise effectively; Harsh condition adaptability: Capable of working stably under high continuous pressure (280 bar) and intermittent peak pressure (300 bar, max 320 bar shock pressure), adapting to hydraulic oils with different kinematic viscosities and frequent displacement adjustment. It performs reliably on construction, mining, marine and road machinery under severe working conditions.
1. Can you provide quality certification for Danfoss hydraulic pumps and motors?
Yes. We can supply formal test reports and actual running test videos for all Danfoss hydraulic pumps and motors to verify product performance and
quality.
2. Are your Danfoss parts original new products?
All items are 100% brand new original genuine parts. A large number of mainstream models are available in stock for fast delivery.
3. Can you adjust stock units to fit my working condition?
Sure. We can modify in-stock Danfoss pumps or motors according to your site parameters to achieve perfect matching and normal operation.
4. Do you support discontinued Danfoss model replacement service?
We offer professional matching selection scheme and compatible replacement solution for obsolete stopped production models.
5. How fast can I get my ordered hydraulic components?
In-stock models can be shipped out within short time. Custom modified products will be finished and delivered efficiently.
6. Is it hard to replace old Danfoss hydraulic motor or pump?
We will recommend the most compatible replacement model and offer technical guidance for easy installation and replacement.
7. What guarantee can you offer on product stability?
All original parts own stable performance. Complete test data and videos can be provided before shipment for your confirmation.
8. Can you help me confirm the correct model for my machine?
We support professional model selection, stock modification and discontinued model upgrade solution to meet your equipment demands.
Main Specifications
1 General Specifications (All Models)
| Category | Item | Specification | Remarks |
| Basic Structure | Type | Swash-plate axial piston variable pump, 9 pistons | Single-stage, self-priming |
| Circuit | Open hydraulic circuit | Not for closed-loop hydrostatic drive | |
| Rotation | R = Clockwise (RH); L = Counter-clockwise (LH) | View from shaft end | |
| Hydraulic Fluid | Recommended Oil | ISO VG 32 / VG 46 / VG 68 anti-wear hydraulic oil | For construction & industrial machinery |
| Kinematic Viscosity | 20 ~ 100 mm²/s (operation) | Improper viscosity causes wear & noise | |
| Min 10 mm²/s (cold start) | |||
| Fluid Cleanliness | ISO 4406: 18/15 | System filter: 10 μm minimum | |
| Water Content | ≤ 0.1% | Excess water leads to cavitation & seal failure | |
| Temperature | Continuous Oil Temp | -20 ℃ ~ +80 ℃ | Optimal: 40 ~ 60 ℃ |
| Peak Oil Temp | ≤ 90 ℃ (max 30 min) | Not for long-term high temp operation | |
| Ambient Temp | -30 ℃ ~ +60 ℃ | Suitable for outdoor job sites | |
| Material & Protection | Housing | High-strength cast iron HT250 | Vibration & impact resistance |
| Piston / Valve Plate | Carburized alloy steel + copper alloy | Wear-resistant friction pair | |
| Standard Seal | A1N: Nitrile Rubber (NBR) | Compatible with standard hydraulic oil | |
| Ingress Protection | IP54 | Dust & splash water resistant | |
| Mounting | Position | Horizontal preferred; Vertical allowed | Vertical: oil level above pump inlet |
| Flange | SAE standard / Metric flange | AAA/NNN = flange option codes | |
| Max Tilt Angle | ≤ 15° | Excessive angle reduces self-priming | |
| Self-priming | Max Vacuum | ≤ 0.07 bar | Avoid cavitation |
| Recommended Height | Pump center ≤ 0.5 m below oil level | Higher installation requires lower speed |
2 Main Performance Parameters by Model
2.1 ERR100B Series
| Item | Value | Notes |
| Displacement Range | 0 ~ 100 cm/r (infinitely variable) | For BS/LS/PC controls |
| Rated Pressure | 28 MPa (280 bar) | Continuous operation |
| Intermittent Peak Pressure | 30 MPa (300 bar) | Max 10 s per cycle |
| Shock Pressure | 32 MPa (320 bar) | Ultimate limit, no frequent use |
| Rated Speed | 2400 rpm | Standard operating speed |
| Max Allowable Speed | 2600 rpm | Only for low-pressure short-time use |
| Min Stable Speed | 500 rpm | Displacement control fails below this |
| Theoretical Flow @2400 rpm | 240 L/min | Full displacement |
| Theoretical Flow @2600 rpm | 260 L/min | Max speed flow |
| Rated Torque @28 MPa | 445.6 N路m | Full displacement torque |
| Max Input Power @2400 rpm | 112 kW | Total rated power |
| Weight | 35 ~ 48 kg | Depends on control & port options |
| Allowable Axial Load | Inlet: 2846 N; Outlet: 7740 N | Shaft load limit |
2.2 ERR130B Series
| Item | Value | Notes |
|---|---|---|
| Displacement Range | 0 ~ 130 cm³/r | Full variable |
| Rated Pressure | 28 MPa (280 bar) | Unified pressure class |
| Intermittent Peak Pressure | 30 MPa (300 bar) | Short-time overload |
| Shock Pressure | 32 MPa (320 bar) | Ultimate pressure |
| Rated Speed | 2400 rpm | Standard speed |
| Max Allowable Speed | 2500 rpm | Lower max speed for longer life |
| Min Stable Speed | 500 rpm | Idle limit |
| Theoretical Flow @2400 rpm | 312 L/min | Full flow |
| Theoretical Flow @2500 rpm | 325 L/min | Max flow |
| Rated Torque @28 MPa | 579.3 N·m | Full displacement torque |
| Max Input Power @2400 rpm | 145.6 kW | Rated power |
| Weight | 42 ~ 52 kg | Larger cavity |
| Allowable Axial Load | Inlet: 3120 N; Outlet: 8150 N | Reinforced bearing |
2.3 ERR147C Series (Reinforced & Low-Noise Version)
| Item | Value | Notes |
|---|---|---|
| Displacement Range | 0 ~ 147 cm³/r | Equipped with NL low-noise module |
| Rated Pressure | 28 MPa (280 bar) | Main working pressure |
| Intermittent Peak Pressure | 30 MPa (300 bar) | Short overload |
| Shock Pressure | 32 MPa (320 bar) | Ultimate pressure |
| Rated Speed | 2300 rpm | Low rated speed for large displacement |
| Max Allowable Speed | 2400 rpm | Over-speed strictly prohibited |
| Min Stable Speed | 550 rpm | Higher idle limit |
| Theoretical Flow @2300 rpm | 338.1 L/min | Rated flow |
| Theoretical Flow @2400 rpm | 352.8 L/min | Max flow |
| Rated Torque @28 MPa | 655.1 N·m | Full displacement torque |
| Max Input Power @2300 rpm | 157.8 kW | Rated power |
| Weight | 48 ~ 56 kg | Thickened housing + noise reduction structure |
| Noise Level | 72 ~ 78 dB(A) | 3~5 dB lower than B type |
| Allowable Axial Load | Inlet: 3400 N; Outlet: 8600 N | Highest load capacity in series |
3.3 Control Code Definition
| Code | Control Type | Function | Typical Application |
|---|---|---|---|
| BS | Pressure Compensator | Constant pressure output | Clamping, pressure holding circuit |
| LS | Load Sensing | On-demand flow, energy saving | Main pump for construction machinery |
| PC | Constant Power | Constant torque, anti-engine overload | Loader, road roller |
| LB | Constant Flow | Stable flow regardless of pressure | Conveying & feed mechanism |
| RP | Remote Pressure Control | External pilot regulation | Central control system |
| AG | Electro-Proportional | Electric signal displacement adjustment | Automatic hydraulic system |
3.4 Service Life Data
| Working Pressure | Average Bearing Life | Piston Assembly Life |
|---|---|---|
| 14 MPa | ≥77200 h | ≥120000 h |
| 21 MPa | ≥19800 h | ≥45000 h |
| 26 MPa | ≥9700 h | ≥22000 h |
