CAT VP Series Low Pressure Variable Pressure Hydraulic Pump for Excavators
Key attributes:Industry-specific attributes
Warranty : 1 Year
Displacement : Other
Pump Type :Vane Pump
Other attributes:Showroom Location
Place of Origin : Zhejiang, China
Weight ： 5
Warranty : 1 Year
Displacement : Other
Pump Type :Vane Pump
Other attributes:Showroom Location
Place of Origin : Zhejiang, China
Weight ： 5
Send Inquiry
Product Introduction
Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. is one of the leading manufacturers and suppliers of cat vp series low pressure variable pressure hydraulic pump for excavators in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Also, OEM&ODM service is available.
Product Description
Model Designation
| VP | 20 | A2 | R |
| Series | Flow code | pressure range | Rotation |
| VP1 | 12,15,20 | A1 8-20 B2 15-35 C3 30-70 | R-Right hand for clockwise L-Left hand forclockwise |
| VP2 | 30,40 |
Technical Data
| Model | Flow code (cc/rev) | Max.pressure (MPa) | Speed range (rpm) | Piping size | Weight (kg) | ||
| Inlet | Outlet | Drain port | |||||
| VP1-12 | 6.6 | 70 | 800~1800 | 1/2" | 3/8" | 1/4" | 5 |
| VP1-15 | 8.3 | ||||||
| VP1-20 | 11.1 | ||||||
| VP2-30 | 16.6 | 3/4" | 1/2" | 1/4" | 9.1 | ||
Hot Tags: cat vp series low pressure variable pressure hydraulic pump for excavators, China cat vp series low pressure variable pressure hydraulic pump for excavators manufacturers, suppliers, denison t67db pump, cat t6dm, vickers 70160 pump, 30vq pump, parker T7, polyhydron plunger pump
