XLF-A2FM Axial Piston Fixed Pump Pressure max 450 bar Flow rate 5 to 1000

|

 Product technical data

XLF-A2FM Axial Piston Fixed Pump Features

- Fixed pump with axial tapered piston rotary group ofbent-axis design, for hydrostatic drives in an open circuit

- For use in mobile and stationary applications- The flow is proportional to the drive speed and displacement

- The drive  shaft bearings are designed for the bearing servicelife requirements usually encountered in these areas

- High power density

- Small dimensions

- High total efficiency

- Economical design

- One-piece tapered piston with piston rings for sealing

|

 XLF-A2FM Axial Piston Fixed Pump Product detail picture

|

 Application Video

|

 XLF-A2FM Axial Piston Fixed Pump Technical data

Technical data
Table of values
Size				5	10	12	16	23	28	32	107	125	160	180
Displacement geometric, per  revolution	Vg		cm³	4.93	10.3	12	16	22.9	28.1	32	106.7	125	160.4	180
Nominal pressure  Pnom    bar				315	400	400	400	400	400	400	400	400	400	400
Maximum pressure  Pma    bar				350	450	450	450	450	450	450	450	450	450	450
Nnom1) rpm				10000	8000	8000	8000	6300	6300	6300	4000	4000	3600	3600
Maximum speed	nmax2)  rpm			11000	8800	8800	8800	6900	6900	6900	4400	4400	4000	4000
Inlet flow 3)at nnanQv      lmin				49	82	96	128	144	177	202	427	500	577	648
Torque 4) at pnom M      Nm				24.7	66	76	102	146	179	204	679	796	1021	1146
Rotary stiffness  C      kNm/rad				0.63	0.92	1.25	1.59	2.56	2.93	3.12	11.2	11.9	17.4	18.2
Moment of inertia for rotary group		Jrw    kg·m²		0.00006	0.0004	0.0004	0.0004	0.0012	0.0012	0.0012	0.0116	0.0116	0.022	0.022
Maximum angular acceleration	a      rad/s⊃2;			5000	5000	5000	5000	6500	6500	6500	4500	4500	3500	3500
Case volume       V					0.17	0.17	0.17	0.2	0.2	0.2	0.8	0.8	1.1	1.1
Weight (approx.)  M      kg				2.5	5.4	5.4	5.4	9.5	9.5	9.5	32	32	45	45
Size				200	250	355	500	710	1000
Displacement geometric,          Vg     cm³ per  revolution				200	250	355	500	710	1000
Nominal pressure  Pnom   bar				400	350	350	350	350	350
Maximum pressure  Dma    bar				450	400	400	400	400	400
Nnom1) rpm				2750	2700	2240	2000	1600	1800
Maximum    speed     nmax2)				3000
Iplet flow 3)at nnom qv       lmin				550	675	795	1000	1136	1600
Torque 4  at pnom M      Nm				1273	1393	1978	2785	3955	5570
Rotary stiffness  C      kNm/rad				57.3	73.1	96.1	144	270	324
Moment of inertia for rotary group		Jrw    kg·m		0.0353	0.061	0.102	0.178	0.55	0.55
Maximum  angular acceleration		a      rad/s⊃2;		11000	10000	8300	5500	4300	4500
Case volume       V				2.7	2.5	3.5	4.2	8	8
Weight(approx.)   M      kg				66	73	110	155	325	336
