XLF-150T Quantitative Vane Pump 150T-48/61/75/94/116/125/150-FR Hydraulic High-pressure Vane Oil Pump for Injection Molding Machines

XLF-150T Quantitative Vane Pump 150T-48/61/75/94/116/125/150-FR Hydraulic High-pressure Vane Oil Pump for Injection Molding Machines

Key attributes
Industry-specific attributes
Warranty 1 Year
Displacement Other
Pump Type Vane Pump
Other attributes
Showroom Location None
Place of Origin Fujian,CN
Brand Name Furnan
Condition New
Product name Hydraulic Vane Pump
Color Customer's Requirement
Material Carbon Steel
Application Industrial machine
Structure Vane Pump
Standard or Nonstandard Standrad
Type hydraulic pump
After Warranty Service No service
Local Service Location None
After-sales Service Provided Online support
Packaging and delivery
Packaging Details 1. Pack the pump in a transparent plastic bag;
2. Put it into the carton and seal it with tape;
3. The default carton packaging, if there is a requirement for wooden box packaging, remarks are required;
We can also make packaging according to customer requirements. Including nameplate, carton pattern and pallet size and weight

Selling Units: Single item
Single package size: 20X25X20 cm
Single gross weight: 26.000 kg

Quantity:
Availability:





Inquire Add to Basket

Model:
150T
Brand:
XLF
Code:
VP0005

Product Description

Product Name	XLF-150T Quantitative Vane Pump 150T-48/61/75/94/116/125/150-FR Hydraulic High-pressure Vane Oil Pump for Injection Molding Machines
Feature	High Pressure,Low Noise,Reliable quality
Max pressure	21MPa
Speed	800-1800RPM
Popular model	150t-48-fr; 150t-61-fr; 150t-75-fr; 150t-94-fr; 150t-116-fr; 150t-125-fr; 150t-150-fr
Application	Injection molding machine,cutting machine,plastic machine,leather machine,blowing machine,forging and engineering machinery field.etc

Product Details

Product advantagesThe advantages of this vane pump are first and foremost our "letter vane pump" with "high volumetric efficiency", long life and extremely low noise value. There are single and double pump configurations, allowing you to choose the pump set that works best for you. Widely used in machine tools, injection molding machines, die-casting machines, rubber machinery and various hydraulic systems, etc.
