PAVC
XLF
00001
|
Product technical data
XLF-PAVC Axial Piston Fixed Pump Features
1. Fully interchangeable with the original brand
2. Very competitive price
3. Low noise, high efficiency, high reliability, long service life
4. Small size, high power density
5. Excellent oil absorption properties.
6. 1 year warranty
7. For engineering equipment, Marine and boating and industrial equipment, etc.
8. For axial piston pump with open loop.
9. Continuous working pressure up to 138 bar, instantaneous maximum working pressure up to 207 bar.
10. Flow proportional to drive speed and displacement and can be achieved by adjusting the variable lock Angle
11. There are constant pressure, constant power pressure, constant voltage flow and other control methods, as well as the reaction rate control
12. Drive shaft can withstand axial and radial loads
13. Sae and iso mounting flange
14. For the structure of the axis of passage and for a multi-loop system
15. Start at any time under pressure.
|
XLF-PAVC Axial Piston Fixed Pump Product detail picture
|
Application Video
|
XLF-PAVC Axial Piston Fixed Pump Technical data
 | ||||||||||
| Quick Reference Data Chart | ||||||||||
| Pump Mode | Displacement CM⊃1;/REV (INP/REV) | Pump Delivery @21 bar (300 PSl n LPM (GPM) | Approx.Noise Levels dB(A @Full Flow 1800 RPM (1200 RPM) 34 bar 69 bar 138 bar 207 ba | Input Power A 1800 RPM,Maximum Displacement & 207 bar (3000 PSI | Operating Speed RPM (Maximum) | Pressure har IPSI Continyous (Maximum | ||||
| 1200 RPM | 1800 RPM | (500 PSI | (1000 PSI) | (2000 PSI) | (3000 PSI) | |||||
| PAVC33 | 33 (2.0) | 39.4(10.4) | 59.0(15.6 | 75(69 | 76(72 | 78(75 | 79(77 | 21.3 kw (28.5 hp | 3000 | 207(3000) |
| PAVC38 | 38(2.3 | 45.0(11.9) | 67.8(17.9) | 75 (69 | 76(72 | 78(75 | 79(77 | 24.6 kw(33.0 hp | 3000 | 207 (3000) |
| PAVC65 | 65(4.0 | 78.7 (20.8 | 118.1 (31.2) | 77 (75 | 78(76 | 80(78 | 81(79 | 43.1 kw(57.8hp) | 3000 | 207(3000) |
| PAVC100 | 100 (6.1) | 119.6(31.6) | 79.8(47.5) | 83(77) | 82 (78) | 82(79 | 85(80 | 71.2 kw(95.5hp) | 2600 | 207 (3000) |
| Snce many variables such as mounting,tank stye,plant layout etc,effec noise levels,it cannot be assumed that the above readings wil be equal to those in the field.The above values ane for guidance in Selecting the proper pump.Noise levels are A weighted,mean sound pressure levels at 1 meter rom the pump,measured and recorded in accordance with applicabie ISO and NFPA standards. | ||||||||||
XLF-PAVC Applicable model
PAVC389R42A16 PAVC389L42A16 PAVC389BR4A16 PAVC389BR4216 PAVC38B2R4P16 PAVC38B2R4C16 PAVC38BL4AP16 PAVC38BL42M16 PAVC38BL42A16 PAVC38BR42W16 PAVC38BR42M16 PAVC38BR4AP16 PAVC38BR4AM16 PAVC38R42HM16 PAVC38R42AP16 PAVC38S2L4C16 PAVC38S2L4216 PAVC38SR42A16 PAVC38SR4HP16 PAVC38SR4HM16 PAVC38BR4CM16 PAVC38BR42A16 PAVC388L42AP16 PAVC3892L42C16 PAVC3892L42A16 PAVC3892R4AP16 PAVC38B2L4AP16 PAVC38B2L45A16 PAVC38B2L42C16 PAVC38B2L42A16 PAVC389R42CM16 PAVC389BL42A16 PAVC389B2R4A16 PAVC3898L42A16 PAVC388R42AP16 PAVC382R42AM16 PAVC38B2R45A16 PAVC38B2R42H16 PAVC38B2R42C16 PAVC38B2R42A16 PAVC38B2R4AP16 PAVC38B8L42A16 PAVC38BR42AP16 PAVC389BL45AP16 | PAVC389B8L42A16 PAVC389B2L4AP16 PAVC389B2R42AP16 PAVC389B2L42AP16
PARKER派克变量柱塞泵PAVC65系列 PAVC65R5M PAVC65L413 PAVC65R413 PAVC658R413 PAVC652R413 PAVC652L413 PAVC65BL413 PAVC65L4213 PAVC65R4H13 PAVC65R4S13 PAVC65R4P13 PAVC65R4M13 PAVC65R4C13 PAVC65R4A13 PAVC65R4513 PAVC65L4H13 PAVC65L4C13 PAVC65L4A13 PAVC65R4213 PAVC65L4M13 PAVC65BR413 PAVC652L4A13 PAVC652R4213 PAVC652R4S13 PAVC652R4M13 PAVC652R4H13 PAVC652R4C13 PAVC652R4A13 PAVC652R4513 PAVC65BL4213 PAVC65B2R413 PAVC65B2L413 PAVC659R4M13 PAVC659R4C13 PAVC659R4A13 PAVC659R4213 PAVC659L4A13 PAVC659L4213 | PAVC65BL4A13 PAVC65R42A13 PAVC65L4HP13 PAVC65L45A13 PAVC65L42S13 PAVC65L42M13 PAVC65R42S13 PAVC65R42P13 PAVC65R42M13 PAVC65R45S13 PAVC65R4AP13 PAVC65R4SE13 PAVC65R4HP13 PAVC65R4HM13 PAVC65R4CP13 PAVC65R45H13 PAVC65R45A13 PAVC65R42H13 PAVC65R42C13 PAVC65L4SP13 PAVC65L4MP13 PAVC65L42H13 PAVC65L42A13 PAVC65BR4H13 PAVC65BR4C13 PAVC65BR4A13 PAVC65BL4P13 PAVC65BL4M13 PAVC65BL4C13 PAVC65B2L4213 PAVC659R42M13 PAVC659L4AP13 PAVC65B2L4P13 PAVC65B2L4M13 PAVC65B8L4213 PAVC65B2R4S13 PAVC65BL42M13 PAVC65BL42A13 PAVC65B2R4M13 PAVC65B2R4C13 PAVC65B2R4A13 PAVC65B2R4513 PAVC65B2L4A13 PAVC65B2L4513 | PAVC659BR4213 PAVC659BL4A13 PAVC659BR4A13 PAVC659BL4213 PAVC65BR42A13 PAVC65BL4AP13 PAVC65BR4MP13 PAVC65BR4AP13 PAVC65L42HM13 PAVC65L4MEP13 PAVC65R42AP13 PAVC65R45HM13 PAVC65R42HP13 PAVC65R42HM13 PAVC65BR42M13 PAVC65BR42H13 PAVC65BR42C13 PAVC652L45H13 PAVC652L45A13 PAVC652L42M13 PAVC652L42C13 PAVC652L42A13 PAVC652R42A13 PAVC652R42C13 PAVC652R42H13 PAVC652R42M13 PAVC652R45H13 PAVC652R4AP13 PAVC652R4CP13 PAVC6592L4A13 PAVC659B2L413 PAVC6592R4P13 PAVC6592R4M13 PAVC6592R4H13 PAVC6592R4A13 PAVC6592R4513 PAVC652R4HM13 PAVC652L4AP13 PAVC652R42AM13 PAVC652R42CP13 PAVC6592L42H13 PAVC6592L42A13 PAVC6592L4HM13 PAVC6592L4AP13 |
PAVC6592R45M13 PAVC6592R4AP13 PAVC6598L42A13 PAVC6592R4HM13 PAVC652L4HMP13 PAVC659B2R4C13 PAVC659B2R4A13 PAVC659B2R4213 PAVC659B2L4A13 PAVC659B2L4213 PAVC659BR42P13 PAVC659BR4AP13 PAVC65B2L42A13 PAVC65B2R42P13 PAVC65B2R42C13 PAVC65B2R42A13 PAVC65B2R45P13 PAVC65B2R4AP13 PAVC65BL42AP13 PAVC65B8R42C13 PAVC65B8L42A13 PAVC65B2R4MP13 PAVC65B2R4ME13 PAVC65B2L4AP13 PAVC65B2L45A13 PAVC659BL42A13 PAVC65BR42AP13 PAVC65BR45AP13 PAVC65R42CMP13 PAVC6592R42HM13 PAVC6592L42HM13 PAVC652R42HMP13 PAVC652R42CMP13 PAVC659B8L42A13 PAVC659BL42MP13 PAVC65B2L42CP13 PAVC65B2L42AP13 PAVC659B2R4AP13 PAVC659B2L4AP13 PAVC659B2L42AP13 PAVC659B2R42AP13 PAVC659B2R4HMP13
PARKER派克变量柱塞泵PAVC100系列 | PAVC100R422 PAVC100L422 PAVC1002L422 PAVC1002R422 PAVC100L4222 PAVC100R4222 PAVC100R4S22 PAVC100R4P22 PAVC100R4M22 PAVC100R4H22 PAVC100R4C22 PAVC100R4A22 PAVC100R4522 PAVC100L4P22 PAVC100L4H22 PAVC100L4A22 PAVC100BR422 PAVC100BL422 PAVC10032R422 PAVC1002R4222 PAVC1002L4222 PAVC1002L4A22 PAVC1002L4C22 PAVC1002L4M22 PAVC1002R4522 PAVC1002R4A22 PAVC1002R4C22 PAVC1002R4H22 PAVC100B2L422 PAVC1009R4P22 PAVC1009R4A22 PAVC1009L4A22 PAVC1009L4522 PAVC100B2R422 PAVC100BL4A22 PAVC100BR4222 PAVC100BR4A22 PAVC100C2L422 PAVC100BR4M22 PAVC100C2R422 PAVC100R42A22 PAVC100L45A22 PAVC100L42S22 PAVC100L42P22 | PAVC100R42S22 PAVC100R42P22 PAVC100R42M22 PAVC100R42H22 PAVC100R42C22 PAVC100R45C22 PAVC100R4HP22 PAVC100R4HM22 PAVC10032R4222 PAVC1002R4HM22 PAVC1002R4HP22 PAVC1002R4ME22 PAVC1002R42M22 PAVC1002R42P22 PAVC1002L4HM22 PAVC1002L4AP22 PAVC1002R42A22 PAVC1009B2R422 PAVC1009BR4A22 PAVC1009BL4M22 PAVC1009BL4A22 PAVC1009L42A22 PAVC1009R4HM22 PAVC1009BR4P22 PAVC1009BR4M22 PAVC1009B3L422 PAVC100B2L4M22 PAVC100B2R4222 PAVC100B2L4A22 PAVC100B32L422 PAVC100B2R4M22 PAVC100B2R4H22 PAVC100B2R4C22 PAVC100B2R4A22 PAVC100B2R4522 PAVC100R42AM22 PAVC100L42CP22 PAVC100BL42A22 PAVC100C2L4A22 PAVC100C2L4222 PAVC100BR4AP22 PAVC100BR45C22 PAVC100BR42A22 PAVC100BL4AP22 | PAVC100B3R4A22 PAVC100B3R4222 PAVC100B3L4A22 PAVC100B3L4222 PAVC1009B2L4A22 PAVC1009B2L4M22 PAVC1009B2R4C22 PAVC1009B2R4A22 PAVC100932R4M22 PAVC100932R4A22 PAVC100B32L4A22 PAVC100B32L4P22 PAVC100B32R4S22 PAVC100B32R4C22 PAVC100B32R4A22 PAVC100B8R42C22 PAVC100B3R4CP22 PAVC100D32L4A22 PAVC100C2R42A22 |
|
