F11
XLF
00001
|
Product technical data
XLF-F11 Axial Piston Fixed Pump Features
1. Fully interchangeable with the original brand
2. Very competitive price
3. Low noise, high efficiency, high reliability, long service life
4. Small size, high power density
5. Excellent oil absorption properties.
6. 1 year warranty
7. For engineering equipment, Marine and boating and industrial equipment, etc.
8. For axial piston pump with open loop.
9. Continuous working pressure up to 350 bar, instantaneous maximum working pressure up to 420 bar.
10. Flow proportional to drive speed and displacement and can be achieved by adjusting the variable lock Angle
11. There are constant pressure, constant power pressure, constant voltage flow and other control methods, as well as the reaction rate control
12. Drive shaft can withstand axial and radial loads
13. Sae and iso mounting flange
14. For the structure of the axis of passage and for a multi-loop system
15. Start at any time under pressure.
|
XLF-F11 Axial Piston Fixed Pump Product detail picture
|
Application Video
|
XLF-F11 Axial Piston Fixed Pump Technical data
| Frame size F11 | -5 | -6 | -10 | -12 | -14 | -19 | |
| Displacement [cm3/rev] | 4.9 | 6.0 | 9.8 | 12.5 | 14.3 | 19.0 | |
| Operating pressure | |||||||
| max intermittentl)[bar] | 420 -- | 420 | |||||
| max continuous[bar] | 350- | -350 | |||||
| Motor operating speed [rpm] | |||||||
| max intermittent1 | 1400011200112001030099008900 | ||||||
| max continuous | 128001020010200940090008100 | ||||||
| min continuous | 50 | 50 | |||||
| Max pump selfpriming speed⊃2;) | |||||||
| L or R function;max [rpm] | 4600 - 4200390039003500 | ||||||
| Motor input flow | |||||||
| max intermittent⊃1;)[l/min] | 69 | 67 | 110 | 129 | 142 169 | ||
| max continuous[/min] | 63 | 61 | 100 | 118 | 129 | 154 | |
| Main circuit temp.3),max [C] | 80 | 80 | |||||
| min [C] | -40 | -40 | |||||
| Theoretical torque at 100 bar [Nm] | 7.8 | 9.5 | 15.6 | 19.8 | 22.7 | 30.2 | |
| Mass moment of inertia | |||||||
| x10-3)[kg m²] | 0.16 | 0.39 | 0.39 | 0.40 | 0.42 | 1.1 | |
| Weight [kg | 4.7 | 7.5 | 7.5 | 8.2 | 8.3 | 11 | |
| Frame size F12 Displacement [cm³/rev] Operating pressure max intermittentl)[bar] max continuous [bar] Motor operating speed [rpm] max intermittentl max continuous min continuous | -30 -40 -60 -80 90 -110 -125 -150 -250 | ||||||
| 30.0 40.0 59.8 80.4 93.0 110.1 125.0 150 242 480 480 420 480 480 420 420 420 420 350 420 420 350 350 730067005800530050004800460035003000 670061005300480046004400420032002700 50 -50 3150 2870 2500 2300 2250 2200210017001500 219 268 347 426 465 528 575 525 726 201 244 317 386 428 484 525 480 653 80 -80 40— -40 47.6 63.5 94.9 127.6147.6174.8198.4238.1384.1 1.7 2.9 5 8.4 8.4 11.2 11.2 40 46 12 16.5 21 26 26 36 36 70 77 | |||||||
| Max pump selfpriming speed⊃2;) L or R function;max[rpm] Motor input flow max intermittent!)[l/min] max continuous[l/min] Main circuit temp.3),max [C] | |||||||
| min [C] | |||||||
| Theoretical torque at 100 bar [Nm] Mass moment of inertia x10-3)[kg m²] Weight [kg | |||||||
XLF-F11 Applicable model
F11-005-MB-CN-D-000-0000-00 F11-005-MB-CN-K-110-0000-00 F11-005-MB-CN-K-000-0000-00 F11-005-RB-CN-K-000-0000-00 F11-010-HU-CN-K-201-0000-00 F11-010-LB-CN-K-000-0000-00 F11-010-MB-CN-K-000-0000-00 F11-010-MB-CN-K-209-0000-0X F11-010-MB-CV-K-201-0000-00 F11-010-RB-CN-K-000-0000-00 F11-010-SB-CS-K-000-0000-00 F11-019-LU-SN-S-000-0000-00 F11-019-MB-CN-D-000-0000-00 F11-019-MB-CN-K-000-0000-00 F11-019-MB-CN-K-220-0000-0X F11-019-MB-SN-S-000-0000-00 F11-019-MU-SN-S-000-0000-P0 F11-019-MU-SN-S-000-0000-00 F11-019-MU-SN-T-000-0000-00 F11-019-RB-CN-K-000-0000-00 F11-019-SB-CS-K-000-MUVR-00 F11-019-SB-CS-K-000-MUVL-00 F11-019-SB-CS-K-000-MUVL-P0 F11-019-SB-CS-K-000-0000-P0 F11-019-SB-CS-K-000-0000-00 F11-019-SB-CS-K-201-MUVL-00 F11-019-SB-CS-K-201-0000-00 F11-019-SB-CS-K-390-MUVL-00 F11-019-SB-WS-X-224-MUVL-00 F11-019-SB-XS-X-284-MUVL-00 F11-019-SB-XS-X-298-MUVR-P0 F11-019-SB-XS-X-286-MUVR-00 | F11-005-MB-CV-D-000 F11-005-MB-CV-K-000 F11-005-MB-CV-K-000 F11-005-RB-CV-K-000 F11-010-HU-CV-K-201 F11-010-LB-CV-K-000 F11-010-MB-CV-K-000 F11-010-MB-CV-K-000 F11-010-MB-CV-K-201 F11-010-RB-CV-K-000 F11-010-SB-CS-K-000 F11-019-LU-SV-S-000 F11-019-MB-CV-D-000 F11-019-MB-CV-K-000 F11-019-MB-CV-K-220 F11-019-MB-SV-S-000 F11-019-MU-SV-S-000 F11-019-MU-SV-S-000 F11-019-MU-SV-T-000 F11-019-RB-CV-K-000 F11-019-SB-CS-K-000 F11-019-SB-CS-K-000 F11-019-SB-CS-K-000 F11-019-SB-CS-K-000 F11-019-SB-CS-K-000 F11-019-SB-CS-K-201 F11-019-SB-CS-K-201 F11-019-SB-CS-K-390 F11-019-SB-WS-X-224 F11-019-SB-XS-X-284 F11-019-SB-XS-X-298 F11-019-SB-XS-X-298 |
|
