Home » Hydraulic Products » Hydraulic pump » Vane pump » XLF-28VQH Series Hot Selling Piston Pve5 Parts 28vqh Vane Replacement Hydraulic Pumps 35vq

XLF-28VQH Series Hot Selling Piston Pve5 Parts 28vqh Vane Replacement Hydraulic Pumps 35vq

Warranty
1 Year
Displacement
Other
Pump Type
Cartridge kits

Other attributes

Showroom Location
None
Place of Origin
Fujian, China
Weight
30
Brand Name
Pressure
Hydraulic
Structure
standard
Power
30
Dimension(L*W*H)
standard
Maximum Flow Rate
standard
Standard or Nonstandard
Standard
MOQ
1 Piece
Delivery time
1-15days
Shipment
Support Express . Sea freight . Land freight .Air freight
After Warranty Service
Video technical support
After-sales Service Provided
Online support
Payment Terms
TT\Western Union\ Trade Assurance
Material
Cast Iron

Quantity:
Availability:





Inquire Add to Basket

Model:
28VQH
Brand:
XLF
Code:
VP0001

Product Description

Model NO.

PVXS

Power

Hydraulic

Application

Paver

Performance

No Leak

Standard

Bar

350-420bar

Displacement

67.2-249

Mode

28VQH

Rpm

1500-1800

Control Mode

Df Pressure Control

Height

121-467

Transport Package

Wooden Case

Specification

47x26x31(cm)

Trademark

XLF

Origin

China

HS Code

8413606090

Product Description

Specification

Cartridge Kit
1U2664	1U2667	3G2195	1364815
1U2665	1U2669	3G2196	1U0532
3G2720	1U3953	3G2200	1U2670
3G2722	3G1266	3G2717	1U2671
3G2749	3G1267	3G2718	3G2234
3G2751	3G2834	3G2752	3G2236
3G7658	3G2835	3G7652	3G2238
3G7659	3G2837	3G7653	3G7656
4T3196	3G7651	3G7654	3G7657
9T4038+	3G7664	3G7655	3G7660
1555091	3G7665	3G7662	3G7661
1U2652	3G7666	3G7663	3G7667
1U2666	4T1893	4T0417+	4T0416+
1U2668	4T6869	4T2626+	4T0422+
1U3519	6E4258	9J7891	9T5336+
1U3592	9T2200	6E2396	6E2387+

(F3-)	PC-	20VQ	-5	-R	-10
Front marks	Pump core marks	Models	Displacement code	Direction of rotation	Designing No.
No mark: Nitrile rubber F3: Fluoro rubber	PC-Single Pump kit & Double Vane pump front kit PCT-Double vane pump rear kit	20V 20VQ	2,3,4,5,6,7,8,9,10,11,12,14	(from shaft end pump) L-counterclockwise rotation R-clockwise rotation	10
		25V 25VQ	10,12,14,15,17,19,21
		35V 35VQ	21,25.30,32,35,38,45
		45V 45VQ	42,45,50,57,60,66,75

3G7658	FELLER BUNCHER FB518 HYDRAULIC CONTROL 173B 183B TRACK-TYPE TRACTOR D7F D7G WHEEL LOADER 920 930 WHEEL SKIDDER 528 528B 530B WHEEL TRACTOR 613B 613C 613C II WHEEL TRACTOR-SCRAPER 613G Caterpillar
1U2665	INTEGRATED TOOLCARRIER IT28 IT28B WHEEL LOADER 926 926A 930R G926 Caterpillar
7J7967	HYDRAULIC CONTROL 173B 183B TRACK-TYPE TRACTOR D7G WHEEL LOADER 920 930 WHEEL SKIDDER 528 WHEEL TRACTOR 613 613B 621 Caterpillar

F3	-28VQH	-22	-10	-R
F3: 氟橡胶密封件 F3: Fluoro rubber seals 没有标准密封件 No standar seals	系列 Series	排量代号 Flow code	设计号 Design number	旋转方向（从压力侧板看） Rotation(Viewed from outlet support plate)
F3: 氟橡胶密封件 F3: Fluoro rubber seals 没有标准密封件 No standar seals	28VQH	19 22	10	R-顺时针旋转 R-Right hand for clockwise L-逆时针旋转 L–Left hand forclockwise

系列号 Series	排量代号 Flow code	理论排量 Geometric displacement ml/r	最高连续使用压力 Max.continuous pressure (MPa)	最高压力 Max. pressure (MPa)	最高转速 Max. speed (rpm)
28VQH	19	60	24	26.5	2500
28VQH	22	70	24	26.5	2500

转子内花键齿廓参数 Inside spline tooth outline parameter of rotor
F3	-28VQH	-22	-10	-R
	系列 Series	排量代号 Flow code	设计号 Design number	旋转方向（从压力侧板看） Rotation(Viewed from outlet support plate)
F3: 氟橡胶密封件 F3: Fluoro rubber seals 没有标准密封件 No standar seals	28VQH	19 22	10	R-顺时针旋转 R-Right hand for clockwise L-逆时针旋转 L–Left hand forclockwise
