| Brand: | XLF |
|---|---|
| Condition: | New without factory packaging |
| Model: | 0 510 525 311 |
| Pressure: | 280 BAR |
| RPM: | 3500 RPM |
| Shipping Weight: | 10.6 lbs |
| Shipping Dimensions: | 8.5 x 7.75 x 6.5 in |
| SKU: | D963875 (VIT08) |
| Category: | Hydraulic Gear Pumps |
| Quantity: | |
|---|---|
F124
XLF
F0002
F5100 series high pressure gear pump displacement from 25 to 80 ml/r, the highest pressure can reach 25 MPa, the unique secondary seal structure can effectively improve the performance of the pump, side plate structure advanced, surface coating treatment, pressure and wear resistance, there are many types of connection can be designed as a single pump or multi-pump requirements
| displacement 排量 ml/rev | Shell E 壳体E mm | Rated | Max | Working Speed RPM 工作转速 转/分 Max Min 最高 最低 | Input Power 输入功率 KW |
| Pressure | Pressure | ||||
| 额定压力 | 最高压力 | ||||
| MPa | MPa | ||||
| 25 | 35 | 21 | 25 | 2400 600 | 18.7 |
| 32 | 39 | 21 | 25 | 2400 600 | 27.9 |
| 40 | 43 | 21 | 25 | 2400 600 | 37.3 |
| 50 | 49 | 21 | 25 | 2400 600 | 46.6 |
| 63 | 56 | 21 | 25 | 2400 600 | 55.9 |
| 80 | 66 | 21 | 25 | 2400 600 | 74.5 |
F5100 series high pressure gear pump displacement from 25 to 80 ml/r, the highest pressure can reach 25 MPa, the unique secondary seal structure can effectively improve the performance of the pump, side plate structure advanced, surface coating treatment, pressure and wear resistance, there are many types of connection can be designed as a single pump or multi-pump requirements
| displacement 排量 ml/rev | Shell E 壳体E mm | Rated | Max | Working Speed RPM 工作转速 转/分 Max Min 最高 最低 | Input Power 输入功率 KW |
| Pressure | Pressure | ||||
| 额定压力 | 最高压力 | ||||
| MPa | MPa | ||||
| 25 | 35 | 21 | 25 | 2400 600 | 18.7 |
| 32 | 39 | 21 | 25 | 2400 600 | 27.9 |
| 40 | 43 | 21 | 25 | 2400 600 | 37.3 |
| 50 | 49 | 21 | 25 | 2400 600 | 46.6 |
| 63 | 56 | 21 | 25 | 2400 600 | 55.9 |
| 80 | 66 | 21 | 25 | 2400 600 | 74.5 |
